We have different type of single facer for differnet type of 5 ply plant. Single facer type can be changed according to the output of the plant.
NAM-405D Multi- Cassette Positive Pressure Single Facer
405D Design speed: 250 m/min.
Effective width: 1400mm , 2500mm
Corrugated roller: 405mm
Using negative pressure type design helps the medium paper to press evenly and closer to the surface of corrugating roll to have perfect forming and also get even gluing on the flute tip to have perfect laminating of the single facer.
Quick change rolls in 15 minutes, while replacing the corrugated rolls, the whole complete set of additional rolls with cassette is delivered into the machine by the carriage and matched with the hydraulic motor to be fixed on the base of the machine by the hydraulic system. Quickly and easily complete the corrugated roller replacement.
The corrugating rolls, pressure roll, and glue roll are adopted with the high stability of the airbag control system, also with pneumatic control buffer effect.
Adopt glue width motorized dividing to match the paper width. Idle running motor for glue applicator roll to avoid glue dry. Adjustment for the gap between glue roller by electric. Digital readout for the gap between glue roll and doctor roll.
The movable type glue unit is convenient to clean and maintain.
Easy operation control system. Touchscreen with a colorful drawing display operation state, easy and simple to handle.
Built-in pre-conditioner with the proportional device for the medium moisture and temperature adjustment.
