Thin Blade Slitter Scorer

Thin Blade Slitter Scorer
Thin Blade Slitter Scorer
Send Inquiry
Product Code : 04
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units,
  • Price
  • 250000 INR
Product Specifications
  • Type
  • Blade Slitter Scorer, Other
  • Material
  • Mild Steel
  • Computerized
  • Yes
  • Automatic Grade
  • Automatic
  • Control System
  • Human Machine Interface
  • Voltage
  • 220 - 380 Volt (v)
  • Color
  • White
Product Description

RNN-NC Thin Blade Slitter Scorer

  • Design Speed: 200 m/min, 250 m/min
  • Width: 1400 mm – 2500 mm
  • The memory of 999 order, nonstop changeover or manual change over can be realized.
  • Change over quickly, within 3 to 8 seconds. Application of two machines can realize nonspeed changeover.
  • Automatic Synchronize with the corrugated line and also get in line with manufacture management system. High Compatibility.
  • High quality imported industry and PLC equipped composing the CNC system.
  • There are three type of scores: Concave – Convex (Single Wall), Concave – Convex (Double Wall) and convex- Flat, Which can also be alternated with electrical scoring can also be computer controlled with fine scoring results.
  • Thin tungsten steel alloy blade, Sharp and long life of over 8 million meters.
  • Computer controlled auto grinding and manual grinding also applicable. Alternative grinding the blade when slitting the board. It can increase efficiency.
  • Imported Synchronous belt applied for conveying with higher precision, longer life and lower noise.
Trade Information
  • Payment Terms
  • Cash in Advance (CID), Cash Advance (CA)
  • Supply Ability
  • 1 Unit Per Week
  • Delivery Time
  • 1 Week
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
