Auto Sheet Cutter Machine

Auto Sheet Cutter Machine
Auto Sheet Cutter Machine
Send Inquiry
Product Code : 03
Product Description

Auto Sheet Cutter Machine

 It is perfectly built and designed to increase production and fine cutting of ply board without damaging the flutes of the board as well as plain paper. PIV gear box is provided to ensure accurate cutting of the sheet as per the required length and for ease in adjustment & operation. It can be used independently or can be attached with corrugating machine for online cutting

  • Machine is driven by A.C. frequency drive with provision for synchronization of speed between Sheet Cutter with Corrugating Machine.
  • With A.C. Motor & Starter.
  • Feeding Section with concealed gears.
  • Cutting Section with Blade workable at four edges.
  • Delivery Conveyor with endless Belts.
  • Electronic Sheet counter.
  • Machine is having a special feature of Oil bath gear system with Oil lubricating pump.
  • Machine is fitted with heavy-duty Excel make P.I.V. Gear Bo- with Imported Chain to adjust the length of the sheet to be cut with Gear Ratio 1:5.

Techical Specifications:

Size
(in)
Power Cutting Length
(Min/Max)
Out Put Range
(Rft/Min)
42” 3 20/100 60-200
45” 3 20/100 60-200
52” 3 20/100 60-200
62” 5 20/100 60-200
72” 7.5 20/100 60-200
84” 7.5 20/100 60-200
95” 10 20/100 60-200
